描述
YB3-125 is applicable to a line of AC 50Hz/60Hz, 230V in single pole, 400V in double, three,four poles for protecting overload and short circuit, rated current up to 125A and breaking capacity up t0 15KA. It can also be used for infrequent line conversion under the normal condition.The breaker is applicable to lighting distribution system in industrial enterprise, commercially district, high-rise building and dwelling house. It conforms with the standards of IEC60947-2.
| Pole | 1P,2P,3P,4P |
|---|---|
| Ue | 120/230/400V |
| In | 1, 2, 3, 4, 6, 10, 13, 16, 20, 25, 32, 40, 50, 63, 80, 100, 125A |
| Breaking Capacity | 10KA, 15KA |
| Standard | IEC60947-2 |
